Calgary Fire Department Heavy Rescue #1027-1031

Calgary Fire Department Heavy Rescue #1027-1031

Calgary’s new six-unit lineup features the department’s tried-and-true heavy rescue design. Each rescue is built on a Spartan Metro Star chassis with a 450 HP Cummins power train and an Allison 3000 transmission. An innovative feature, exhaust is diverted to the roof to redirect fumes away from on-ground crews. Each unit also utilizes suspension kneeling, which lowers the apparatus 5” for easier OnScene Solutions compartment access. Calgary’s go-to design includes a Holmatro slide.

For more information about this apparatus, choose one of the options below or contact us for more details.


Cab: Spartan Metro Star LFD w/ 10” RR
Engine: Cummins L9, 450HP
Transmission: Allison EVS 3000
Wheelbase: 202″


Material: Aluminum
Body Length: 18′
Overall Height: 10′ – 4″
Overall Length: 32′ – 10″


  • Onan 30kW PTO Generator
  • OnScene Solutions LED Compartment Lights
  • Whelen LED Warning Light Package
  • Command Light CL615A-HQ Light Tower
  • Hannay Hydrualic Hose Reels With Power Rewind
  • Halmatro CORE Hydraulic Hoses
  • Hannay 100’ Low Pressure Air Hose Reels
  • Whelen M9 LED Scene Lights
  • OnScene Aluminum Heavy-Duty Cargo Slides
